Vane Piston Industrial Water Flow Meter 0.25% 0.5% Accuracy For Water Utility

Shanghai I Fluid Technology Co., Ltd.
Contact Now

Vane Piston Industrial Water Flow Meter 0.25% 0.5% Accuracy For Water Utility

  • 1
  • 2

Brand Name : Iflow

Model Number : YF-F100-2

Certification : ISO9001, CE

Place of Origin : China

MOQ : 50

Price : negotiable

Payment Terms : T/T, L/C, D/P, Western Union

Supply Ability : 1000 sets per month

Delivery Time : 2-4 weeks

Packaging Details : carton / box

Name : Remote magnetic meter

Pipe diameter : 2 - 48"

Pressure rating : PN16, PN25, PN40 Mpa

Tube material : SS316

Electrode : 316L / Hasteloy-C / Ti / Ta / Pt100

Accuracy : 0.25% , 0.5%

Communication : BACNET/Modbus/RS485/4-20 mA

Pipe connect : Flange

Liner material : PTFE

Contact Now

Vane piston flow meter for water utility, communication: Modbus/RS485/Bacnet/4-20ma

Highlights

  • aluminum alloy housing electromagnetic flowmeter, good enclosure.
  • unique 6 layer circuit board design, immune to electromagnetic interference.
  • fault detective supported like excitation circuit turn-off.
  • plug & play terminal block
  • damp-proof sealed sensor treatment
  • reliable blank pipe inspection

Applications

For the UVZ differential pressure flowmeterCompact Orifice Flowmeter

Oil and Gas Production
Refining
Petrochemical
Power
Utilities
Pulp and Paper
Natural Gas

Key features

  • Maximal uptime with dual-compartment transmitter housing that isolates electronics from moisture and contamination
  • Robust structure, fully welded construction designed to withstand sustained vibration
  • Confirm meter calibration without interrupting the process using continuous meter verification
  • Perform easy repairs in the field without the need to replace the entire meter with a replaceable terminal block
  • Advanced diagnostic capabilities and printed reports verify meter performance for compliance with regulatory agencies
  • Simplify configuration and accessibility with an easy-to-use Local Operator Interface

Accuracy

Pipe Dia (mm) Velocity (m/s) Accuracy
3-20 <0.3 + 0.25% FS
0.3-1 + 1.0% Readout
1-15 + 0.25% Readout
25-600 0.1-0.3 + 0.25% FS
0.3-1 + 0.5% Readout
1-15 + 0.3% Readout
700-3000 <0.3 + 0.25% FS
0.3-1 + 1.0% Readout
1-15 + 0.25% Readout

Technical data

Product name Electromagnetic flowmeter
Product type Local|compact display Remote display Signal converter
Model IYF-E IYF-F IRT
Pipe Diameter (mm) DN10-DN2000
Power supply 100-240 VAC / 18-36 VDC
Accuracy + 0.5% + 0.5% + 0.5%
Power consumption <6w <6w <6w
Enclosure rating IP65 IP68 IP65
Liquid temperature -25-120℃ -25-120℃ -25-120℃
Ambient temperature -25-50℃ -25-50℃ -25-50℃
Relative humidity 10-90% 10-90% 10-90%
Meter ratio 1:100 1:100 1:100
Flow direction Bi-direction flow Bi-direction flow Bi-direction flow
Communication RS485 / Bacnet RS485 / Bacnet RS485 / Bacnet
Signal Output 4-20mA/Pulse/Frequency 4-20mA/Pulse/Frequency 4-20mA/Pulse/Frequency

Manufacture process

Vane Piston Industrial Water Flow Meter 0.25% 0.5% Accuracy For Water Utility

Packing

Vane Piston Industrial Water Flow Meter 0.25% 0.5% Accuracy For Water Utility
